DS18 SQCOAX 6.5" 2 Way Coaxial Speaker 180 Watts
The DS18 SQCOAX are for those looking to upgrade their car audio system on a budget. This set can be a DIY installation, but we recommend professional installation.
The Coaxial speaker is a FULL RANGE speaker (high-efficiency midbass and tweeter). The cones are larger than others in their size class to move more air and make more bass. The tweeter projects the high pitches for a complete sound range.
Four-ohm speakers compensate for the undersized wires found in many of today cars, and make the most of every watt your car stereo can deliver.
Specifications
| 6.5" Coaxial Speaker: | |
| Impedance: | 4 Ohms |
| Mode of Frequency Division: | 2 Way |
| RMS Power: | 60 Watts |
| MAX Power: | 180 Watts |
| Sensitivity: | 91dB |
| Frequency Response: | 45Hz - 20KHz |
| Magnet: | NdFeB (Woofer: N38/Tweeter: N35) |
| Cone | |
| Woofer: | Bulletproof Fabric + Rubber Edge |
| Tweeter: | Silk Film Dome |
| Voice Coil | |
| Woofer: | 30mm/Tweeter: 20mm |
| Cone Stand Structure: | Integrated Structure |
| Mounting Depth: | 69mm |
| Mounting Diameter: | 135 mm |
