DS18 INF-LTI20-13AH INFINITE 13 AH Lithium Battery YTX20 Case With Shake and Wake Technology and BMS Perfect for Motorcycles
Boost your Motorcycle or Powersports vehicle with pure power from DS18’s INF-LTI20-13AH. Given 13AH of Lithium these batteries supply EIGHT TO TEN TIMES the power of an AGM battery at half the size.
This long-lasting Lithium Battery offers peak performance through the highest of temperatures, and strong starts through the lowest. These batteries come with the most reliable lithium battery chemistry on the market – LifePo4.
The INF-LTI20-13AH delivers over 1000-amps of starting power, 2500W of Burst Power, and quick recharge capabilities. This Lithium Battery is also equipped with a M6x1.0 bolt terminal for easy connectivity to most cables or distribution bars / blocks.
The Electronic Circuit Board in the INF-LTI20-13AH provides maximum safety protection with active cell balancing for long-lasting reliability.
Only to be maintained with the DS18 INF-LTI3.5 A battery maintainer. Any other charger or maintainer can damage the unit.
Order the INF-LTI20-13AH to increase the power of your Motorcycle or Powersports Vehicle!
Highlights
- 8” x 3.4” x 5.6” - L x W x H
- High Performance at High Temperatures
- Long Lasting Battery Life
- Very Fast Charge Rate
- Powerful Starts at Low Temperatures
- Shake And Wake Auto Start Technology
- Lightweight Design That Delivers Heavy Duty Power
- Group 20 Battery
- Cell Balancing Electronic Circuit Board
- 3V Nominal Voltage; 1000A Cranking Amps; 2500W Burst Power
Great For
- Motorcycle Audio
- Powersports Audio
- Car Audio
Technical Details
Download INF-LTI20-13AH Product Manual
| SPECIFICATIONS |
|
| Battery Type |
Lithium / LifePo4 |
| Capacity |
13Ah (Not Pb Eq) 52 Pb Eq |
| Nominal Voltage |
13.3V |
| Continuous Discharge Current |
140A |
| Maximum Discharge Current (Burst) |
210A |
| Cranking Amps (CA) |
1000A |
| Continuous Watts |
2000W |
| Burst Watts |
2500W |
| Minimum Discharge Voltage (BMS cutoff) |
11.5v-12.2v based on SOC % (Reserves 20% SOC to restart) |
| Maximum Input Charging Current |
60A |
| Maximum Input Charging Voltage |
14.8V (15V BMS Cutoff) |
| Life Cycles |
>2000 @ 80% DOD |
| Nominal Operating Temperature Range |
-20~60°C / -4~140°F |
| Bolt / Terminal Type |
4 x M6 x 1.0 |
| Positive Terminal Position |
Left / Right (Rotatable) |
| Battery Group |
20 |
| Features |
|
| Battery Management System (BMS) |
Yes |
| Shake & Awake Technology |
Yes |
| Cell Balancing Electronic Circuit Board |
Yes |
| Measurement |
|
| Overall Length |
6.8" / 175mm |
| Overall Depth |
3.4" / 87mm |
| Overall Height |
5.6" / 143mm |
| Overall Height (Without Terminals) |
5.6" / 143mm |
| Weight |
4.62Lb / 2.1Kg |
